| Фотографии | Производитель. Часть # | Акции | Цены | А | Таблицы данных | Packaging | Series | ProductStatus | MountingType | CoilVoltage | ContactForm | ContactRating(Current) | SwitchingVoltage | CoilCurrent | CoilType | Features | TerminationStyle | SealRating | CoilInsulation | MustOperateVoltage | MustReleaseVoltage | OperateTime | ReleaseTime | OperatingTemperature | ContactMaterial |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
G2R-1A4 DC18RELAY GEN PURPOSE SPST 8A 18V |
2793 | 0.00 |
ДобавитьНемедленный |
Datenblatt |
Tray | G2R | Active | Through Hole | 18VDC | SPST-NO (1 Form A) | 8 A | 380VAC, 125VDC - Max | 29.4 mA | Non Latching | - | PC Pin | Sealed - Fully | - | 12.6 VDC | 2.7 VDC | 15 ms | 5 ms | -40°C ~ 70°C | Silver Alloy |
|
|
G2R-1A4 DC9RELAY GEN PURPOSE SPST 8A 9V |
3396 | 0.00 |
ДобавитьНемедленный |
Datenblatt |
Tray | G2R | Active | Through Hole | 9VDC | SPST-NO (1 Form A) | 8 A | 380VAC, 125VDC - Max | 58.8 mA | Non Latching | - | PC Pin | Sealed - Fully | - | 6.3 VDC | 1.35 VDC | 15 ms | 5 ms | -40°C ~ 70°C | Silver Alloy |
|
|
G2R-1A4-T130 DC15RELAY GEN PURPOSE SPST 8A 15V |
2602 | 0.00 |
ДобавитьНемедленный |
Datenblatt |
Tray | G2R | Obsolete | Through Hole | 15VDC | SPST-NO (1 Form A) | 8 A | 380VAC, 125VDC - Max | 35.3 mA | Non Latching | - | PC Pin | Sealed - Fully | - | 10.5 VDC | 2.25 VDC | 15 ms | 5 ms | -40°C ~ 70°C | Silver Alloy |
|
|
G2R-1A4-T130 DC22RELAY GEN PURPOSE SPST 8A 22V |
2822 | 0.00 |
ДобавитьНемедленный |
Datenblatt |
Tray | G2R | Obsolete | Through Hole | 22VDC | SPST-NO (1 Form A) | 8 A | 380VAC, 125VDC - Max | 24.1 mA | Non Latching | - | PC Pin | Sealed - Fully | - | 15.4 VDC | 3.3 VDC | 15 ms | 5 ms | -40°C ~ 70°C | Silver Alloy |
|
|
G2R-1A4-T130 DC48RELAY GEN PURPOSE SPST 8A 48V |
2304 | 0.00 |
ДобавитьНемедленный |
Datenblatt |
Tray | G2R | Obsolete | Through Hole | 48VDC | SPST-NO (1 Form A) | 8 A | 380VAC, 125VDC - Max | 11.5 mA | Non Latching | - | PC Pin | Sealed - Fully | - | 33.6 VDC | 7.2 VDC | 15 ms | 5 ms | -40°C ~ 70°C | Silver Alloy |
|
G2R-1A AC100/(110)RELAY GEN PURPOSE SPST 10A 110V |
3052 | 0.00 |
ДобавитьНемедленный |
Datenblatt |
Tray | G2R | Active | Through Hole | 110VAC | SPST-NO (1 Form A) | 10 A | 380VAC, 125VDC - Max | 10.6 mA | Non Latching | - | PC Pin | Sealed - Flux Protection | - | 88 VAC | 33 VAC | 15 ms | 10 ms | -40°C ~ 70°C | Silver Alloy |
|
G2R-1A-AC110RELAY GEN PURPOSE SPST 10A 110V |
2349 | 0.00 |
ДобавитьНемедленный |
Datenblatt |
Tray | G2R | Active | Through Hole | 110VAC | SPST-NO (1 Form A) | 10 A | 380VAC, 125VDC - Max | 10.6 mA | Non Latching | - | PC Pin | Sealed - Flux Protection | - | 88 VAC | 33 VAC | 15 ms | 10 ms | -40°C ~ 70°C | Silver Alloy |
|
G2R-1A-AC220RELAY GEN PURPOSE SPST 10A 220V |
2591 | 0.00 |
ДобавитьНемедленный |
Datenblatt |
Tray | G2R | Active | Through Hole | 220VAC | SPST-NO (1 Form A) | 10 A | 380VAC, 125VDC - Max | 4.1 mA | Non Latching | - | PC Pin | Sealed - Flux Protection | - | 176 VAC | 66 VAC | 15 ms | 10 ms | -40°C ~ 70°C | Silver Alloy |
|
|
G2R-1A-AP-DC12RELAY GEN PURPOSE SPST 10A 12V |
3907 | 0.00 |
ДобавитьНемедленный |
Datenblatt |
Tray | G2R | Active | Through Hole | 12VDC | SPST-NO (1 Form A) | 10 A | 380VAC, 125VDC - Max | 43.6 mA | Non Latching | - | PC Pin | Sealed - Flux Protection | - | 8.4 VDC | 1.8 VDC | 15 ms | 5 ms | -40°C ~ 70°C | Silver Alloy |
|
|
G2R-1A-ASI AC120RELAY GEN PURPOSE SPST 10A 120V |
3762 | 0.00 |
ДобавитьНемедленный |
Datenblatt |
Tray | G2R | Active | Through Hole | 120VAC | SPST-NO (1 Form A) | 10 A | 380VAC, 125VDC - Max | 7.5 mA | Non Latching | - | PC Pin | Sealed - Flux Protection | - | 96 VAC | 36 VAC | 15 ms | 10 ms | -40°C ~ 70°C | Silver Alloy |
|
|
G2R-1A-ASI-DC110RELAY GEN PURPOSE SPST 10A 110V |
3087 | 0.00 |
ДобавитьНемедленный |
Datenblatt |
Tray | G2R | Active | Through Hole | 110VDC | SPST-NO (1 Form A) | 10 A | 380VAC, 125VDC - Max | 4.8 mA | Non Latching | - | PC Pin | Sealed - Flux Protection | - | 77 VDC | 16.5 VDC | 15 ms | 5 ms | -40°C ~ 70°C | Silver Alloy |
|
|
G2R-1A-ASI DC18RELAY GEN PURPOSE SPST 10A 18V |
2151 | 0.00 |
ДобавитьНемедленный |
Datenblatt |
Tray | G2R | Active | Through Hole | 18VDC | SPST-NO (1 Form A) | 10 A | 380VAC, 125VDC - Max | 29.4 mA | Non Latching | - | PC Pin | Sealed - Flux Protection | - | 12.6 VDC | 2.7 VDC | 15 ms | 5 ms | -40°C ~ 70°C | Silver Alloy |
|
|
G2R-1A-ASI-DC48RELAY GEN PURPOSE SPST 10A 48V |
3493 | 0.00 |
ДобавитьНемедленный |
Datenblatt |
Tray | G2R | Active | Through Hole | 48VDC | SPST-NO (1 Form A) | 10 A | 380VAC, 125VDC - Max | 11.5 mA | Non Latching | - | PC Pin | Sealed - Flux Protection | - | 33.6 VDC | 7.2 VDC | 15 ms | 5 ms | -40°C ~ 70°C | Silver Alloy |
|
G2R-1-AC110RELAY GEN PURPOSE SPDT 10A 110V |
3014 | 0.00 |
ДобавитьНемедленный |
Datenblatt |
Tray | G2R | Obsolete | Through Hole | 110VAC | SPDT (1 Form C) | 10 A | 380VAC, 125VDC - Max | 10.6 mA | Non Latching | - | PC Pin | Sealed - Flux Protection | - | 88 VAC | 33 VAC | 15 ms | 10 ms | -40°C ~ 70°C | Silver Alloy |
|
|
G2R-1 AC200/(220)RELAY GEN PURPOSE SPDT 10A 220V |
2588 | 0.00 |
ДобавитьНемедленный |
Datenblatt |
Tray | G2R | Active | Through Hole | 220VAC | SPDT (1 Form C) | 10 A | 380VAC, 125VDC - Max | 5.3 mA | Non Latching | - | PC Pin | Sealed - Flux Protection | - | 176 VAC | 66 VAC | 15 ms | 10 ms | -40°C ~ 70°C | Silver Alloy |
|
|
G2R-1-AC50RELAY GEN PURPOSE SPDT 10A 50V |
3899 | 0.00 |
ДобавитьНемедленный |
Datenblatt |
Tray | G2R | Active | Through Hole | 50VAC | SPDT (1 Form C) | 10 A | 380VAC, 125VDC - Max | 18 mA | Non Latching | - | PC Pin | Sealed - Flux Protection | - | 40 VAC | 15 VAC | 15 ms | 10 ms | -40°C ~ 70°C | Silver Alloy |
|
|
G2R-1A-DC18RELAY GEN PURPOSE SPST 10A 18V |
3731 | 0.00 |
ДобавитьНемедленный |
Datenblatt |
Tray | G2R | Active | Through Hole | 18VDC | SPST-NO (1 Form A) | 10 A | 380VAC, 125VDC - Max | 29.4 mA | Non Latching | - | PC Pin | Sealed - Flux Protection | - | 12.6 VDC | 2.7 VDC | 15 ms | 5 ms | -40°C ~ 70°C | Silver Alloy |
|
|
G2R-1A DC20RELAY GEN PURPOSE SPST 10A 20V |
2957 | 0.00 |
ДобавитьНемедленный |
Datenblatt |
Tray | G2R | Active | Through Hole | 20VDC | SPST-NO (1 Form A) | 10 A | 380VAC, 125VDC - Max | 26.5 mA | Non Latching | - | PC Pin | Sealed - Flux Protection | - | 14 VDC | 3 VDC | 15 ms | 5 ms | -40°C ~ 70°C | Silver Alloy |
|
|
G2R-1A-DC9RELAY GEN PURPOSE SPST 10A 9V |
3595 | 0.00 |
ДобавитьНемедленный |
Datenblatt |
Tray | G2R | Active | Through Hole | 9VDC | SPST-NO (1 Form A) | 10 A | 380VAC, 125VDC - Max | 58.8 mA | Non Latching | - | PC Pin | Sealed - Flux Protection | - | 6.3 VDC | 1.35 VDC | 15 ms | 5 ms | -40°C ~ 70°C | Silver Alloy |
|
|
G2R-1A-E-250DC24RELAY GEN PURPOSE SPST 16A 24V |
3101 | 0.00 |
ДобавитьНемедленный |
Datenblatt |
Tray | G2R | Active | Through Hole | 24VDC | SPST-NO (1 Form A) | 16 A | 380VAC, 125VDC - Max | 21.8 mA | Non Latching | - | PC Pin | Sealed - Flux Protection | - | 16.8 VDC | 3.6 VDC | 15 ms | 5 ms | -40°C ~ 70°C | Silver Alloy |
