| Фотографии | Производитель. Часть # | Акции | Цены | А | Таблицы данных | Packaging | Series | ProductStatus | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Polarization | Ratings | Applications | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
EEE-FK1H390SPCAP ALUM 39UF 20% 50V SMD |
2327 | 0.70 |
ДобавитьНемедленный |
Datenblatt |
Tape & Reel (TR),Cut Tape (CT) | FKS | Active | 39 µF | ±20% | 50 V | 880mOhm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 107.2 mA @ 120 Hz | 160 mA @ 100 kHz | - | - | 0.248 Dia (6.30mm) | 0.240 (6.10mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
860160474014CAP ALUM 150UF 20% 25V RADIAL |
3525 | 0.36 |
ДобавитьНемедленный |
Datenblatt |
Cut Tape (CT),Tape & Box (TB) | WCAP-ATLL | Active | 150 µF | ±20% | 25 V | - | 7000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 306.24 mA @ 120 Hz | 528 mA @ 100 kHz | 520 mOhms | 0.138 (3.50mm) | 0.315 Dia (8.00mm) | 0.512 (13.00mm) | - | Through Hole |
|
UZR1V100MCL1GBCAP ALUM 10UF 20% 35V SMD |
3698 | 0.70 |
ДобавитьНемедленный |
Datenblatt |
Tape & Reel (TR),Cut Tape (CT) | UZR | Not For New Designs | 10 µF | ±20% | 35 V | - | 1000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive | 29 mA @ 120 Hz | 43.5 mA @ 10 kHz | - | - | 0.197 Dia (5.00mm) | 0.156 (3.95mm) | 0.209 L x 0.209 W (5.30mm x 5.30mm) | Surface Mount |
|
UWP1H0R1MCL1GBCAP ALUM 0.1UF 20% 50V SMD |
3508 | 0.75 |
ДобавитьНемедленный |
Datenblatt |
Tape & Reel (TR),Cut Tape (CT) | UWP | Active | 0.1 µF | ±20% | 50 V | - | 1000 Hrs @ 85°C | -40°C ~ 85°C | Bi-Polar | - | General Purpose | 1 mA @ 120 Hz | 1.5 mA @ 10 kHz | - | - | 0.157 Dia (4.00mm) | 0.217 (5.50mm) | 0.169 L x 0.169 W (4.30mm x 4.30mm) | Surface Mount |
|
EMZA100ADA102MJA0GCAP ALUM 1000UF 20% 10V SMD |
235 | 1.13 |
ДобавитьНемедленный |
Datenblatt |
Tape & Reel (TR),Cut Tape (CT) | Alchip™- MZA | Active | 1000 µF | ±20% | 10 V | - | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 510 mA @ 120 Hz | 850 mA @ 100 kHz | 80 mOhms | - | 0.394 Dia (10.00mm) | 0.413 (10.50mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
ULR2G8R2MNL1GSCAP ALUM 8.2UF 20% 400V SMD |
2448 | 1.20 |
ДобавитьНемедленный |
Datenblatt |
Tape & Reel (TR),Cut Tape (CT) | ULR | Active | 8.2 µF | ±20% | 400 V | - | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 50 mA @ 120 Hz | 80 mA @ 10 kHz | - | - | 0.394 Dia (10.00mm) | 0.433 (11.00mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
ULV2C220MNL1GSCAP ALUM 22UF 20% 160V SMD |
3713 | 1.20 |
ДобавитьНемедленный |
Datenblatt |
Tape & Reel (TR),Cut Tape (CT) | ULV | Active | 22 µF | ±20% | 160 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 65 mA @ 120 Hz | 104 mA @ 10 kHz | - | - | 0.394 Dia (10.00mm) | 0.433 (11.00mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
ULR2E150MNL1GSCAP ALUM 15UF 20% 250V SMD |
3223 | 1.20 |
ДобавитьНемедленный |
Datenblatt |
Tape & Reel (TR),Cut Tape (CT) | ULR | Active | 15 µF | ±20% | 250 V | - | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 50 mA @ 120 Hz | 80 mA @ 10 kHz | - | - | 0.394 Dia (10.00mm) | 0.433 (11.00mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
UWP1H010MCL1GBCAP ALUM 1UF 20% 50V SMD |
2977 | 0.75 |
ДобавитьНемедленный |
Datenblatt |
Tape & Reel (TR),Cut Tape (CT) | UWP | Active | 1 µF | ±20% | 50 V | - | 1000 Hrs @ 85°C | -40°C ~ 85°C | Bi-Polar | - | General Purpose | 8.4 mA @ 120 Hz | 12.6 mA @ 10 kHz | - | - | 0.157 Dia (4.00mm) | 0.217 (5.50mm) | 0.169 L x 0.169 W (4.30mm x 4.30mm) | Surface Mount |
|
|
ULV2D180MNL1GSCAP ALUM 18UF 20% 200V SMD |
3214 | 1.20 |
ДобавитьНемедленный |
Datenblatt |
Tape & Reel (TR),Cut Tape (CT) | ULV | Active | 18 µF | ±20% | 200 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 65 mA @ 120 Hz | 104 mA @ 10 kHz | - | - | 0.394 Dia (10.00mm) | 0.433 (11.00mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
UZR0J470MCL1GBCAP ALUM 47UF 20% 6.3V SMD |
3142 | 0.71 |
ДобавитьНемедленный |
Datenblatt |
Tape & Reel (TR),Cut Tape (CT) | UZR | Not For New Designs | 47 µF | ±20% | 6.3 V | - | 1000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive | 33 mA @ 120 Hz | 67.5 mA @ 10 kHz | - | - | 0.197 Dia (5.00mm) | 0.156 (3.95mm) | 0.209 L x 0.209 W (5.30mm x 5.30mm) | Surface Mount |
|
UZS1E330MCL1GBCAP ALUM 33UF 20% 25V SMD |
2065 | 0.71 |
ДобавитьНемедленный |
Datenblatt |
Tape & Reel (TR),Cut Tape (CT) | UZS | Not For New Designs | 33 µF | ±20% | 25 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | - | - | General Purpose | 52 mA @ 120 Hz | 78 mA @ 10 kHz | - | - | 0.248 Dia (6.30mm) | 0.181 (4.60mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
UPS2G100MHD1TOCAP ALUM 10UF 20% 400V RADIAL |
3760 | 1.14 |
ДобавитьНемедленный |
Datenblatt |
Cut Tape (CT),Tape & Box (TB) | UPS | Not For New Designs | 10 µF | ±20% | 400 V | - | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 72 mA @ 120 Hz | 115.2 mA @ 10 kHz | - | 0.197 (5.00mm) | 0.492 Dia (12.50mm) | 1.063 (27.00mm) | - | Through Hole |
|
ULT2H3R3MNL1GSCAP ALUM 3.3UF 20% 500V SMD |
2899 | 1.14 |
ДобавитьНемедленный |
Datenblatt |
Tape & Reel (TR),Cut Tape (CT) | ULT | Active | 3.3 µF | ±20% | 500 V | - | 2000 Hrs @ 125°C | -40°C ~ 125°C | Polar | - | General Purpose | 35 mA @ 120 Hz | 52.5 mA @ 10 kHz | - | - | 0.394 Dia (10.00mm) | 0.433 (11.00mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
UVR1J101MPD1TDCAP ALUM 100UF 20% 63V RADIAL |
2303 | 0.21 |
ДобавитьНемедленный |
Datenblatt |
Tape & Box (TB) | UVR | Not For New Designs | 100 µF | ±20% | 63 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 300 mA @ 120 Hz | 450 mA @ 10 kHz | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.492 (12.50mm) | - | Through Hole |
|
UPJ1V181MPD6TDCAP ALUM 180UF 20% 35V RADIAL |
2995 | 0.60 |
ДобавитьНемедленный |
Datenblatt |
Cut Tape (CT),Tape & Box (TB) | UPJ | Not For New Designs | 180 µF | ±20% | 35 V | - | 5000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 500 mA @ 120 Hz | 700 mA @ 10 kHz | 180 mOhms | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.650 (16.50mm) | - | Through Hole |
|
UVR2A331MHD1TOCAP ALUM 330UF 20% 100V RADIAL |
556 | 1.14 |
ДобавитьНемедленный |
Datenblatt |
Cut Tape (CT),Tape & Box (TB) | UVR | Not For New Designs | 330 µF | ±20% | 100 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 760 mA @ 120 Hz | 1.14 A @ 10 kHz | - | 0.197 (5.00mm) | 0.492 Dia (12.50mm) | 1.063 (27.00mm) | - | Through Hole |
|
UPJ1A222MHD1TOCAP ALUM 2200UF 20% 10V RADIAL |
2815 | 1.21 |
ДобавитьНемедленный |
Datenblatt |
Cut Tape (CT),Tape & Box (TB) | UPJ | Not For New Designs | 2200 µF | ±20% | 10 V | - | 5000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 1.53 A @ 120 Hz | 1.71 A @ 10 kHz | 45 mOhms | 0.197 (5.00mm) | 0.492 Dia (12.50mm) | 1.043 (26.50mm) | - | Through Hole |
|
UVZ2W010MPDCAP ALUM 1UF 20% 450V RADIAL |
3167 | 0.51 |
ДобавитьНемедленный |
Datenblatt |
Bulk | UVZ | Not For New Designs | 1 µF | ±20% | 450 V | - | 1000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 13 mA @ 120 Hz | 20.8 mA @ 10 kHz | - | 0.138 (3.50mm) | 0.315 Dia (8.00mm) | 0.512 (13.00mm) | - | Through Hole |
|
UUR1J220MNL1GSCAP ALUM 22UF 20% 63V SMD |
3390 | 0.61 |
ДобавитьНемедленный |
Datenblatt |
Tape & Reel (TR),Cut Tape (CT) | UUR | Not For New Designs | 22 µF | ±20% | 63 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | - | - | General Purpose | 96 mA @ 120 Hz | 160.32 mA @ 10 kHz | - | - | 0.315 Dia (8.00mm) | 0.413 (10.50mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
